DiaMedical Diagnostics F2 Fetal Monitor
DiaMedical Diagnostics F2 Fetal Monitor
DiaMedical Diagnostics F2 Fetal Monitor
With its elegant design, foldable screen, and enhanced functionality, the DiaMedical Diagnostics F2 fetal monitor addresses the needs of obstetrical departments in both clinics and hospitals. The F2 is amazingly lightweight and portable, which makes it suitable for outpatient services. With the latest technologies, the F2 offers an extensive set of monitoring parameters such as FHR, TOCO, DECG, IUP and fetal movement.
Ease Of Use
- Single Button Operation simplifies workflow and allows you to integrate patient info with printing
- Single Knob Operation allows you to carry out every configuration to meet the clinical needs of each patient
- 1 MHz waterproof FHR Probe enlarges the penetration and deepens the range of detection to improve fetal monitoring for larger-sized pregnant women. The lower frequency also offers improved protection for the fetus.
Features
- Easy to Read and Operate
- Displays waveforms and digitals simultaneously.
- Simple workflow with silicone buttons for operations.
- 5.6″ foldable black and white screen
- Large numeric and waveform display
- Long life Lithium-ion battery guarantees mobility
- Convenient probe rack and compact design
- Advanced FHR Detection Technology
- Signals Overlap Verification to differentiate between twins FHR
- Signal quality indicator helps to optimize the probe position
- Powerful Data Management
- 12 hours of built-up backup memory for seamless monitoring
- MFM-CNS network for data management on PC
- Insight software for data management on PC
- USB port to enlarge storage capacity
- Flexible Printing Options
- Built-in thermoprinter
- Compatible with 150/152 mm thermal recording paper
- 1/2/3 cm/min real-time printing speed
- 15 mm/sec fast printing speed for history traces
- Dimensions: 350 mm x 300 mm x 104 mm.
- Weight: 7.7 lb (3.5 kg).
- Display:
- 5.6″ LCD.
- Resolution: RGB 640 (W) x 480 (H).
- Ultrasound:
- Technique: Ultrasound Pulse Doppler with autocorrelation.
- Pulse Repetition Rate: 2 KHz.
- Frequency: 1.0 MHz +/- 10%.
- FHR Measurement Range: 50 ~ 240 bpm.
- Resolution: 1 bpm.
- Accuracy: +/- 2 bpm.
- DECG:
- Technique: Peak-peak detection.
- DFHR Measurement Range: 30 ~ 240 bpm.
- Resolution: 1 bpm.
- Accuracy: +/- 1 bpm.
- TOCO:
- Range: 0 – 100%.
- Non-Linear Error: ≤ 10%.
- Resolution: 1%.
- Zero Mode: Automatic / Manual.
- IUP:
- Pressure Range: 0 – 100 mmHg.
- Non-Linear Error: ≤ +/- 3 mmHg.
- Resolution: 1%.
- Zero Mode: Automatic / Manual.
- Automatic Fetal Movement:
- Technique: Pulse Doppler ultrasound.
- Range: 0 – 100%.
- Resolution: 1%.
- Manual Fetal Movement Method: Remote Marker.
- Recorder:
- Recording Paper: Z-fold, 150/152 mm thermosensitive paper.
- Recording Speed: 1/2/3 cm/min, 15 mm/sec for history data.
- Power Supply:
- Operating Voltage: 100 – 240 V.
- Operating Frequency: 50/60 Hz.
- Battery: 14.8 V rechargeable Li-ion battery.
- Shipping Weight: 9 lb.
- Shipping Dimensions: 16″ x 16″ x 9″.
