Physio-Control LifePak 15 Defibrillator
Physio-Control LifePak 15 Defibrillator
Physio-Control LifePak 15 Defibrillator
The LIFEPAK® 15 monitor/defibrillator is the standard in emergency care for ALS teams who want the most clinically innovative, operationally effective, and LIFEPAK TOUGH™ device available today.
- Reconditioned
- Biphasic
- New defibrillator pads included
- Optional adult or pediatric paddles available
- Compact and portable
- The 15 weighs about 17.5 lbs
- Works with QUIK-COMBO pacing/ defibrillation/ECG electrodes
- Convenient upgrades
- Component based system designed with long-term use in mind
- Guidance for compliance with HIPAA Security Standards for a Covered Entity available
- One (1) year warranty
Features
- The LIFEPAK 15 monitor/defibrillator has six main operating modes:
- AED Mode: for automated ECG analysis and a prompted treatment protocol for patients in cardiac arrest.
- Manual Mode: for performing manual defibrillation, synchronized cardioversion, noninvasive pacing, and ECG and vital sign monitoring.
- Archive Mode: for accessing stored patient information.
- Setup Mode: for changing default settings of the operating functions.
- Service Mode: for authorized personnel to perform diagnostic tests and calibrations.
- Demo Mode: for simulated waveforms and trend graphs for demonstration purposes.
Display
- Size (active viewing area): 212 mm (8.4 in) diagonal; 171 mm (6.7 in) wide x 128 mm (5.0 in) high
- Resolution: display type 640 dot x 480 dot color backlit LCD
- User Selectable Display Mode: full color or SunVue™ display high contrast
- Display: a minimum of 5 seconds of ECG and alphanumerics for values, device instructions, or prompts
- Display: up to three waveforms
- Waveform Display Sweep Speed: 25 mm/sec for ECG, Sp02, IP, and 12.5 mm/sec for CO2
Battery Specifications
- Battery Type: Lithium-ion
- Weight: ≤0.6kg (1.3lb)
- Charge Time (with fully depleted battery): 4 hours and 15 minutes (typical)
- Battery indicators: Each battery has a fuel gauge that indicates its approximate charge. A fuel gauge that shows two or fewer LEDs after a charge cycle indicates that the battery should be replaced.
- Charging Temperature Range: 5° to 45°C (41° to 113°F)
- Operating Temperature Range: 0° to 45°C (32° to 113°F)
- Short Term (<1 week) Storage Temperature Range: -20° to 60°C (-4° to 140°F)
- Long Term (>1 week) Storage Temperature Range: 20° to 25°C (68° to 77°F)
- Operating and Storage Humidity Range: 5 to 95% relative humidity, non-condensing
- Expertly reconditioned Physio-Control LIFEPAK 15 Defibrillator is available in many configurations with AED, Pacing, SpO2, SPCO, EtCO2, NIBP, and Bluetooth features
- Component based system works with QUIK-COMBO pacing/defibrillation/ECG electrodes
- Includes a set of defibrillator pads and a 1 year warranty
Product Highlights
- Expertly reconditioned Physio-Control LIFEPAK 15 Defibrillator is available in many configurations with AED, Pacing, SpO2, SPCO, EtCO2, NIBP, and Bluetooth features
- Component based system works with QUIK-COMBO pacing/defibrillation/ECG electrodes
- Includes a set of defibrillator pads and a 1 year warranty
