SimLabSolutions Vantage Med Surg Tutor Bed

(0) No Reviews yet
SKU: BS029901
$3,650.00

SimLabSolutions Vantage Med Surg Tutor Bed


The Vantage Med Surg Tutor Bed by SimLabSolutions and DiaMedicalUSA was specifically designed to simulate hospital environments for healthcare training. It has all of the features of a brand name medical-surgical hospital bed with an affordable price for education.  The Vantage Med Surg Tutor Bed is ideal for all types of skills practice, validations and simulations:

  • Bed frame smoothly moves into 5 functional positions for patient positioning and care:
    • High/Low
    • Fowler
    • Knee
    • Trendelenberg
    • Reverse Trendelenberg
  • CPR release lever rapidly lowers the head of the bed for chest compressions
  • Headboard is easily removed and may be used as a backboard for CPR
  • Large brake pedal is located at the foot of the bed
  • Integrated Foley bag and IV pole holders on the bed frame
  • Fowler angle indicator and auto-contour for patient positioning


The Vantage bed was designed to comply with Hospital Bed Safety Workgroup (HBSW) and International Electrotechnical Commission (IEC) requirements.  The unique side rail design minimizes the openings between the side rails, mattress, head/foot boards and bed frame to prevent entrapment.


Silent Linak actuators provide smooth, reliable movement of the bed frame. The modular battery backup system and actuators are protected against spraying and splashing water. The motors are reliable, durable, and equipped with overheat protection. The side rails lower and tuck under the bed for easy navigation through doorways. The durable 5” caster wheels move easily over door sills and four integrated roller bumpers prevent damage to walls and door jambs. The smooth powder-coated metal and polypropylene surfaces are easily cleaned for infection control.


The Vantage bed is a great investment for skills and simulation labs. It comes with a 3-year warranty, a bed sheet set and a new mattress.  The Vantage bed is designed for many years of use with minimal preventative maintenance.


Specifications
  • Weight Capacity: 550 lbs
  • Overall Length: 92″
  • Overall Width: 42″ Siderails Up/40″ Siderails Down
  • Patient Surface: 36″ x 80″
  • Bed Frame Height Range: 16″ x 27″
  • Directional Caster Wheels Diameter: 5″
  • Brake Mechanism: Central Locking
  • Motors: Silent Linak Actuators
  • Warranty: 3 Years

Specifications

Weight Capacity: 550 Lbs (250 Kg)
Dimensions
  • Length: 88″ (234 cm)
  • Width:
    • With Side Rails Raised: 42″ (107 cm)
    • With Side Rails Lowered: 41″ (104 cm)
  • Patient Surface:
    • 35″ x 77″ (89 x 196 cm)
  • Height Range to the Mattress Surface:
    • Highest Position: 29″ (74 cm)
    • Lowest Position: 18″ (46 cm)
  • Caster Diameter: 5″ (13 cm)
Positions
  • Trendelenberg/Reverse Trendelenberg: ± 12°
  • Back Rest: 0° – 65°
  • Knee Gatch: 0° – 30°
Electrical
  • Voltage: 110 V @ 60 Hz or 220 V @ 50 Hz
