SimLabSolutions 24" Discover Headwall Package

Available in a variety of value-added packages with simple installation and maintenance, Discover Headwalls serve as a cornerstone for any simulation or skills lab. Designed to simulate oxygen, air, and suction using a single air source, the Discover Headwall connects to an external Silent Air Compressor to provide realistic functionality.

The Classic Functioning Headwall Package includes:

1.SimLabSolutions 24” Discover Headwall

Integrated Fixtures Include:

• Duplex electrical receptacle, red
• Vacuum slide
• Air, vacuum, and oxygen outlets
• Wall mounting strips (for wall-mount models)

Headwall Specifications:

• Ohmeda connections
• Horizontal: 24" L × 12.5" H × 4" D
• 8" Power cord
• 1-Year parts warranty

2.Complete Accessories Package

• Oxygen flowmeter
• Medical air flowmeter
• Vacuum regulator with tubing nipple “T”
• (2) Humidifiers
• (2) Nasal cannulas
• Suction tubing

3.Silent Air Compressor

• Silent running
• Automatic operation
• In-Line regulator with moisture trap
• Tank and regulated pressure gauge
• Thermal protection
• Suitcase design
• 1-Year warranty

Silent Air Compressor Specifications:

• 1/2 HP
• 110-Volt single phase
• 2.15 CFM displacement
• 1.7 CFM @40 psi
• 114 psi Max pressure
• <40 dBA
• 2.25 Gallon tank
• 17.7" H × 7.9" W × 17" D
• 58 lbs
