EDAN DUS60 Ultrasound
EDAN DUS60 Ultrasound
EDAN DUS60 Ultrasound
The DUS60 is equipped with innovative technologies that enhance daily efficiency. This Diagnostic Ultrasound Machine is designed to withstand all working conditions while remaining intuitive for users, making it the premiere choice for ultrasound imaging.
An impressive new compact ultrasound system, the DUS60 provides superb value and quality across the entire range of applications. The addition of PW Doppler increases diagnostic information content.
Features:
- Full keyboard
- USB & DICOM Export
- Two (2) Transducer Ports
- Built-in battery provides up to 2 hours of point-of-care imaging
- Large capacity data storage (504 MB)
- One touch image optimization via smart IP key
- User-defined keys to customize your work-flow
- Intelligent 8-segment TGC for precise adjustment
- Innovative Technologies: Intelligent 8-segment TGC, five (5) frequency transducers, phase inversion harmonic imaging, data transfer via USB & DICOM
- Compact Design: 12.1" TFT-LCD monitor, two (2) active & exchangeable connectors, backlit easy-to-use control panel, multiple peripheral ports
Includes:
- User manual
- Transducer cable holder
- Ground cable
- Luxury travel bag
- Battery
- Ultrasound gel (250g)
- Transducer holder
- Power cord (USA standard)
- Luxury Mobile Trolley
Does not Include Transducer
Probes/Transducers Compatible with DUS60:
- Convex Array Transducer C361-2 (2.5/3.5/4.5/H2.5/H2.7MHz)
- Linear Array Transducer L761-2 (6.5/7.5/8.5/H4.5/H4.7MHz)
- Linear Array Transducer L743-2 (6.5/7.5/8.5/H4.5/H4.7MHz)
- Micro-Convex Array Transducer C611-2 (5.5/6.5/7.5/H4.5/H4.7MHz)
- Transvaginal Transducer E611-2 (5.5/6.5/7.5/H4.5/H4.7MHz)
- Endorectal Transducer E741-2 (6.5/7.5/8.5/H4.5/H4.7MHz)
EDAN DUS60 Digital Ultrasonic Diagnostic Imaging System Specifications:
General:
- Gray Scales: 256
- Scanning Angle: Up to 152° (transducer dependent)
- Scanning Depth: From 19 mm to 324 mm (transducer dependent)
Functions:
- Body Mark: > 130 types
- Transducer auto-detection
Peripheral Ports: S-video output, Video output, VGA output, 2 USB ports, Ethernet port, Remote control, and Footswitch port
Measurement and Calculation:
- B-mode: Distance, circumference, area, volume, angle, ratio, %stenosis, histogram
- M-mode: Distance, time, heart rate, slope
- Doppler: Time, heart rate, velocity, acceleration, trace, and RI
Power Supply: 100 - 240 V (50/60 Hz)
Dimensions: 13.0" L x 8.7" W x 12.6" H (330 mm x 220 mm x 320 mm)
Net Weight: 15.7 lbs (7.1 kg)
Applied Technologies: Tissue Specific Imaging (TSI), Tissue Harmonic Imaging (THI), Digital Beam-Forming (DBF), Dynamic Receiving Focusing (DRF), Real-time Dynamic Aperture (RDA), Dynamic Frequency Scanning (DFS), and Dynamic Apodization.
Display Modes: B, B+B, 4B, B+M, M, and PW.
Display: 12.1" TFT-LCD monitor with date, Time, Probe Name, Probe Frequency, Frame Rate, Patient Name, Patient ID, Hospital Name, Depth, Exam Type, Measurement Values, Body Marks, Annotations, and Probe Position.
Transducer Connections: 2 standard transducer connectors with a maximum frequency up to 10 MHz.
- 12.1" TFT-LCD monitor, two (2) active & exchangeable connectors, backlit easy-to-use control panel, multiple peripheral ports
- Full keyboard
- USB & DICOM Export
- Two (2) transducer ports
- Built-in battery provides up to two (2) hours of point-of-care imaging
